LAN Connection
2N IP Style
®
is connected to the Local Area Network (LAN) via the UTP/STP cable
(Cat 5e or higher) terminated with an RJ-45 (LAN) connector. As the device is
equipped with the Auto-MDIX function, you can use either the straight or crossed
cable version.
Caution
We recommend the use of a LAN surge protection.
We recommend that an SSTP Ethernet cable with a shielded RJ-45
connector is used, which is connected to the switch (with the grounding
option) using the same shielded connector. Thus, the device is grounded
without the need to use grounding terminals.
Tip
Remove the protective connector cover to facilitate the threading of the
UTP/STP cable RJ terminal into the device box.
