2.4 Extending Module Connection
The functions can be extended by connecting any of the available 2N IP 2N IP Style
® ®
Verso extending modules via the VBUS connector. Choose the proper accessories for
each type of extending module installation.
Info Panel
125 kHz RFID card reader
13.56 MHz NFC RFID card reader
Secured 13.56 MHz NFC RFID card reader
125 kHz, 13.56 MHz, NFC Bluetooth & RFID reader
125 kHz, secured 13.56 MHz, NFC Bluetooth & RFID reader
Bluetooth reader
Induction loop
Fingerprint scanner
I/O module
Wiegand module
Tamper switch
Security relay
Module Bus Interconnection
All the extending modules, except for the tamper switch, are interconnected via a bus.
The bus starts on the basic unit and goes over all the modules. The order of modules
on the bus is irrelevant. And it also irrelevant which bus connector on the module is
used as the input and which is used as the output.
The modules include a 220 mm long interconnecting cable, the Wiegand (9155037)
and I/O modules include an 80 mm long bus cable.(9155034)
It is possible to order separate bus cables of the length of 1 m, 3 m or 5 m (Part No.
), which are intended for remote module 9155050/9155054/9155055 respectively
installations. Typically, they help install an RFID card reader on the opposite side of
the wall on which is installed. This cable may only be used once on the 2N IP Style
®
bus. The total length of all the bus cables used in these extended installations may not
exceed 7 m.

2N IP Style Specifications

General

Tamper Switch	Yes
Power Supply	12V DC
Ingress Protection	IP65
Inputs	2
Operating Voltage	12V DC
Speaker Impedance	8 Ohm
