2N TELEKOMUNIKACE a.s., www.2n.cz 63/105
Caution
Purchase a frame / mounting box for the extending modules to be
connected according to the type of installation. This does not apply to
the I/O, Wiegand and tamper switch extending modules.
Module Power Supply
All the modules, except for the tamper switch, are powered from a bus. 2N IP Style
®
The available bus power output depends on the power supply type. The basic unit can
use a 4A power supply to increase the power available to the modules connected.
Power supply Specification Available power output
External supply 12 V ±15 % / 4 A DC up to 48
PoE+ 802.3at up to 21.6 W
Combined External supply + PoE+
Infopanel Module
The Infopanel module ( ) is one of the 2N IP Verso system elements Part No. 9155030
®
and is used for inserting and backlighting the printed information.
The module contains two bus connectors.2N IP Style
®
These two connectors are fully interchangeable and can be used either as inputs
from the basic unit or outputs to other modules.
If this module is the last one on the bus, one of the connectors remains
unconnected.
The module package includes a 220 mm long interconnecting cable.
Name tag dimensions: 69.2 (W) x 86.7 (H) mm (dimensional tolerance: +0; 0.5
mm).
Refer to for the printing template.www.2n.cz
