AUTO DIAGNOSTIC
External Digital Input Signals
3B6 Operator Manual
I 01234567 8 90123
-------- * -----1
PO7
Digital Inputs (I)
The upper row indicates the Input number, while the lower row indicates its status.
The symbol “*” means active Input, the symbol “-” means non active Input .
• A2B = 4
• Bypass key switch = 6
• Proximity switch = 7
NOTE : The combination of the Inputs status automatically selects the proper Operating
Mode (OM ) and the corresponding load Table, depending on the machine model.
