AUTO DIAGNOSTIC
Rotation sensor
3B6 Operator Manual
The displayed parameters are as follows:
• R1 : Channel 1 or A of rotation pot values between 0 to 360 degrees
• R2 : Channel 2 or B of rotation pot values between 0 to 360 degrees
R1 181.8
R2 183.4
P010
