72 CHAPTER 8: SETTING UP VIRTUAL LANS
3 Add port 12 on Switch 1 to the VLANs
Add port 12 on Switch 1 as a tagged member of both VLANs 1 and 2 so
that all VLAN traffic is passed over the link to Switch 2.
4 Configure the VLANs on Switch 2
Define VLAN 2. VLAN 1 is the default VLAN and already exists.
5 Add endstation ports on Switch 2 to the VLANs
Place the endstation ports in the appropriate VLANs as untagged
members.
6 Add port 11 on Switch 2 to the VLANs
Add port 11 on Switch 2 as a tagged member of both VLANs 1 and 2 so
that all VLAN traffic is passed over the link to Switch 1.
7 Check the VLAN membership for both switches
The relevant ports should be listed in the VLAN members summary.
8 Connect the switches
Connect port 12 on Switch 1 to port 11 on Switch 2.
The VLANs are now configured and operational and the endstations in
both VLANs can communicate with their relevant servers.
