3M™ Tip/Nozzle/Air Cap Selection Guide
Tip/Nozzle (For Spray Gun Model 12SZ)
Size Description Replacement PN
.021 (0.5 mm) Full Composite Needle 91-006-021-D
Composite Nozzle 91-148-021
.028 (0.7 mm) Full Composite Needle 91-006-028-D
Composite Nozzle 91-148-028
.036(0.9 mm) Full Composite Needle 91-006-036-D
Composite Nozzle 91-148-036
.043 (1.1 mm) Full Composite Needle 91-006-043-D
Composite Nozzle 91-148-043
.051 (1.3 mm) Full Composite Needle 91-006-051-D
Composite Nozzle 91-148-051
.061 (1.5 mm) Full Composite Needle 91-006-061-D
Composite Nozzle 91-148-061
.072 (1.8 mm) Full Composite Needle 91-006-072-D
Composite Nozzle 91-148-072
.084 (2.0 mm) Full Composite Needle 91-006-084-D
Composite Nozzle 91-148-084
.110 (3.0 mm) Full Composite Needle 91-006-110-D
Composite Nozzle 91-148-110
3M™ Tip/Nozzle/Air Cap Selection Guide
Standard Tip/Nozzle
Size Description Replacement PN
.021 (0.5 mm) Replacement Tips 91-107-021/4 (Pack of 4)
Standard Tip/Nozzle Set 91-143-021DT
.028 (0.7 mm) Replacement Tips 91-107-028/4 (Pack of 4)
Standard Tip/Nozzle Set 91-143-028DT
.036 (0.9 mm) Replacement Tips 91-107-036/4 (Pack of 4)
Standard Tip/Nozzle Set 91-143-036DT
.043 (1.1 mm) Replacement Tips 91-107-043/4 (Pack of 4)
Standard Tip/Nozzle Set 91-143-043DT
.051 (1.3 mm) Replacement Tips 91-107-051/4 (Pack of 4)
Standard Tip/Nozzle Set 91-143-051DT
.061 (1.5 mm) Replacement Tips 91-107-061/4 (Pack of 4)
Standard Tip/Nozzle Set 91-143-061DT
.072 (1.8 mm) Replacement Tips 91-107-072/4 (Pack of 4)
Standard Tip/Nozzle Set 91-143-072DT
.084 (2.0 mm) Replacement Tips 91-107-084/4 (Pack of 4)
Standard Tip/Nozzle Set 91-143-084DT
.110 (3.0 mm) Replacement Tips 91-107-110/4 (Pack of 4)
Standard Tip/Nozzle Set 91-143-110DT
Air Cap
Air Cap Number Description Replacement PN
2 Aluminum Air Cap 91-071-2
3 Aluminum Air Cap 91-071-3
4 Aluminum Air Cap 91-071-4
5 Aluminum Air Cap 91-071-5
6 Aluminum Air Cap 91-071-6
7 Aluminum Air Cap 91-071-7
8 Aluminum Air Cap 91-071-8
Delrin® Air Cap 91-009-8
9 Aluminum Air Cap 91-071-9
Delrin® Air Cap 91-009-9
10 Aluminum Air Cap 91-071-10
Delrin® Air Cap 91-009-10
11 Aluminum Air Cap 91-071-11
Delrin® Air Cap 91-009-11
12 Delrin® Air Cap 91-009-12
13 Delrin® Air Cap 91-009-13
Low CFM Tip/Nozzle (For 19C Spray Gun Only)
Size Description Replacement PN
.028 (0.7 mm) Replacement Tips 97-019-728/4 (Pack of 4)
Low CFM/Gravity Tip/Nozzle Set 97-079-728
.036 (0.9 mm) Replacement Tips 97-019-736/4 (Pack of 4)
Low CFM/Gravity Tip/Nozzle Set 97-079-736
.043 (1.1 mm) Replacement Tips 97-019-743/4 (Pack of 4)
Low CFM/Gravity Tip/Nozzle Set 97-079-743
.051 (1.3 mm) Replacement Tips 97-019-751/4 (Pack of 4)
Low CFM/Gravity Tip/Nozzle Set 97-079-751
.061 (1.5 mm) Replacement Tips 97-019-761/4 (Pack of 4)
Low CFM/Gravity Tip/Nozzle Set 97-079-761
.072 (1.5 mm) Replacement Tips 97-019-772/4 (Pack of 4)
Low CFM/Gravity Tip/Nozzle Set 97-079-772
Air Cap (For 19C Spray Gun Only)
Air Cap Number Description Replacement PN
805 Low CFM Aluminum Air Cap 98-020-805
807 Low CFM Aluminum Air Cap 98-020-807
809 Low CFM Aluminum Air Cap 98-020-809
