Machine Specifications
Item Specification
Acoustic Noise Level
Normal Mode: Typical 32 dB(A)
ECO Mode: Typical 35 dB(A)
Auto Detect & Install
Automatically recognizes the connection of I/O module
Automatically saves user adjustments
Computer Compatibility
Horizontal Sync: 69 kHz
Vertical Sync: 85 Hz
Conditions for usage environment
Rel Humidity:10-80%
Altitude: 0-2286m
Temperature: /10-35C (50-95F)
Dimensions 328.94 x 264.0 x 116.43 mm (13.2 x 10.6 x 4.7 inches)
DMD Native Resolution 1024H x 768V (XGA)
Focus Manual Adjustment
Input / Output Terminals
VGA (mini D-sub 15-pin) connector
Control connector
USB (A-B)
AC power outlet
Input rating 100-240V AC, 50-60 Hz, 4.0A
Lamp Life
3000 hrs at 300W Bright mode
5000 hrs at 180W ECO mode
Languages
English, French, Spanish, Deutsch, Italian, Japanese, Chinese
Traditional, Chinese Simplified, Korean
Lens Focal Length = 6.95 mm
Power Consumption 300W normal operation, 5W standby mode
Video Compatibility
NTSC: M, N, 3.58Mz, 4.43 MHz
PAL: B, D, G, H, I, M, N
SECAM
Wall/Ceiling Mount capability Three screw holes
Weight 4.5kg (10 lbs)
Note: Designs and specifications are subject to change without notice.
