Chapter 3. Installing the Battery Backup Unit
28 3ware 9650SE Serial ATA RAID Controller Installation Guide
Figure 20. Points of connection on the half-height controller
Figure 21. Points of connection on the full-height controller
b) BBU receptacle
c) Hole for posta) Slots for the clips
b) BBU receptacle
c) Hole for post
a) Hole and slots for the clips
