Chapter 1. Getting Started
4 3ware 9650SE Serial ATA RAID Controller Installation Guide
9650SE RAID Controller Card Models
Figure 1. 2-Port 3ware 9650SE-2LP Serial ATA RAID Controller
Figure 2. 4-Port 3ware 9650SE-4LPML Serial ATA RAID Controller
Ports:
0 (on top)
1 (on the
bottom)
Heat Sink
LED Connector
Ports:
0 thru 3
I
2
C connector
BBU connector and hole for postSlots for battery
holder
Heat Sink
LED Connector
