detected face marked with a tracking rectangle in the live view.
Figure 1-2 Configuring Face Detection
3. Configure the sensitivity for face detection.
Sensitivity: Range [1-5]. The value of the sensitivity defines the size of the object which can
trigger the alarm, when the sensitivity is high, a very small object can trigger the alarm.
4. Click the tab to enter the arming schedule setting interface. The time schedule
configuration is identical to configuring an arming schedule for motion detection. Refer to Section 5.2.1
Configuring Motion Detection for more details.
5. Click the tab to select the linkage method taken for the video loss alarm. Available
linkages include Notify surveillance center, Send email, Upload to FTP, Trigger channel, Smart tracking and
Trigger alarm output. Refer to Section 5.2.1 Configuring Motion Detection for details on configuring
linkage methods.
6. Click to save the settings.
CONFIGURING INTRUSION DETECTION
Intrusion detection can set an area in the camera’s field of vision and once the area is entered, a set of alarm
action(s) are triggered.
Steps:
1. Enter the intrusion detection interface: Configuration > Events > Smart Event >Intrusion Detection
2. Toggle the Enable checkbox.
