4B W400 Series User Manual

4B - W4005 BÜHLER ELEVATOR MONITORING SYSTEM R9.6 – 22 May 2020
Page 10 of 48
7.3 W4005NV46AI /B – W400 Series Elevator Controller
Controller Specifications
Supply Voltage:
24V
DC
OR 100-240V
AC
±10% 50/60Hz
Power Dissipation:
25W Max
Alarm Relay Contacts:
1 Pole normally open 8A@ 250VAC AC1
Stop Relay Contacts:
Guided Relay Category B, 1 Pole normally open 8A@ 250VAC AC1
Sensor Supply:
24VDC; Current 800mA maximum (combined over F1 and F2)
Motor Run Input:
24V
DC
Contactor Feedback Input
24V
DC
Power Terminals:
4mm² 14 AWG max
Signal Terminals:
2.5mm² 16 AWG max
Protection:
IP66
Height:
246mm (9.7”)
Width:
188mm (7.4”)
Depth:
102mm (4”)
Fixing Centres:
222mm x 102mm (8.75”x 4”) (AutoCAD Drawing available)
Cable Entry:
3 x 25mm Dia Holes, 1 x 20mm Dia Hole
Weight:
1.3kg (3lbs)
Table 5 – W4005NV46AI /B Controller Specifications
7.3.1. W4005NV46AI /B Controller Fuses
The W400 series controller has three replaceable fuses. Please use the information below when ordering new
fuses.
Fuse Reference
Fuse Value
Fuse Type
4B Part Number
F1, F2, F6
2A; 250V
TR5,Time Delay
FUSE-ELITE-2
F5
200mA
TR5,Time Delay
FUSE-ELITE-200
Table 6 – W4005NV46AI /B Fuse Ratings
7.4 TS1V4AI /B – TouchSwitch™ Alignment Sensor
TouchSwitch Specifications
Supply Voltage:
24V
DC
(TS1V4AI)
Power Consumption:
50mA
Indication:
Red LED indicates when powered up and relay is energized
Adjustment:
Force Sensitivity is factory set to 3.6 kg (8 lb)
Output:
Voltage free changeover relay contact rated at 5A 250vac;
Non-inductive
Body Construction:
Pressed seamless steel, powder coated
Face Construction:
Hardened stainless steel
Cable Length:
3 meters (9ft)
Conductors:
6 cores; 22AWG
Weight:
1.36 kg (3 lb.)
Protection:
IP 66
Dimensions:
86mm (3.5”) Diameter x 44mm (1.75”) Deep
(AutoCAD Drawing Available)
Table 7 - TS1V4AI /B Specifications
