The W4005NV46AI /B controller also has an FTP server. This should only be used for firmware updates. User
should not use this FTP server to store any files as it may become problematic to perform future firmware
updates if not enough free space is left on the device. Please contact 4B sales support to obtain the firmware
update guide.
12.19 Ethernet Data Allocation
Ethernet Data Allocation Table (Output)
ID
Section
Name
Length (Bytes)
Byte Offset
System Status
1
System State
2
0
2
State Time [0.1s]
2
2
3
Flags
2
4
Alarm
4
Shutdown Cause
2
6
5
Time to Shutdown [0.1s]
2
8
6
Muted (Not Active)
2
10
Speed Section
7
Status
2
12
8
Nominal Speed [0.1 %]
2
14
9
Top Speed [0.1 PPM]
2
16
10
Bottom Speed [0.1 PPM]
2
18
11
Calibrated
Single Speed [0.1 PPM]
2
20
12
Calibrated
Differential Speed [0.1 %]
2
22
Misalignment Head
13
Status
2
24
Misalignment Tail
14
Status
2
26
Temperature Sensors
15
Temperature
Alarm Value [°C]
2
28
16
1
Status
2
30
17
Value [0.1 °C]
2
32
18
2
Status
2
34
19
Value [0.1 °C]
2
36
20
3
Status
2
38
21
Value [0.1 °C]
2
40
22
4
Status
2
42
23
Value [0.1 °C]
2
44
Settings
24
SW2 Values
1
46
25
SW1 Values
1
47
26
Main Processor Firmware
Version
2
48
