Page #40 background image
4B - W4005 BÜHLER ELEVATOR MONITORING SYSTEM R9.6 22 May 2020
Page 40 of 48
13. Troubleshooting Guide
Condition
Solution
Power LED is OFF
Check that power is applied to the unit on terminals 25-28
Check that the main input fuse F6 is not damaged
Check that the internal circuitry fuse F5 is not damaged
Alarm / Stop LED is blinking, but no
Alarm present
Unit is not calibrated or waiting for calibration. Please refer to 10.14
for the instruction on how to calibrate the unit. W4005NV46CAI /B
controller MUST be calibrated before it can be used
There is no power to the sensors
Check that the field power fuses (F1 and F2) are not damaged
Check the field wiring to make sure +24VDC supply is delivered to
the sensors
Replace the faulty fuses and sensors as necessary
Sensor in Alarm /Fault
Check if the sensor is in a state of alarm and clear it
Check if the sensor is powered correctly (+24VDC)
Replace the faulty sensor if needed
Bearing Temperature Sensor Alarm
always present
Make sure that switches 3 and 4 within SW2 are set correctly. Refer
to section 10.13.2 - DIP Switches (SW2) for more information
Make sure that the bearings are not faulty and have been greased
correctly
Replace faulty temperature sensors as necessary
Immediate Stop/Shutdown after
calibration
Check that there are no misalignment alarms
Check that the speed sensor is detecting speed (i.e. the output LED
on the sensor is blinking when the shaft is rotating
Check that the motor contactor is wired exactly as shown in this
manual
Elevator is not stopping when alarm is
present
Check that the motor started wiring is correct according to the
drawings specified in this manual in Figure 14.
Table 28 - W4005V46AI-SYSx Troubleshooting Guide
