7.5 P300V34AI /B – Proximity Speed Sensor
P300 Specifications
Supply Voltage:
10-30V
DC
Sensor Output Type:
Opto-Isolated Transistor (NPN or PNP use)
Sensor Output Ratings:
100mA @ 30V
DC
MAX
Maximum Detectable
Speed:
200Hz (1500 RPM MAX shaft speed when used with WG4A-BR mount)
Cable Length:
3metres (9 feet)
Conductors:
4 cores; 22AWG
Detection Range:
12mm
Protection:
IP65
Dimensions:
30mm Diameter x 92mm Long (AutoCAD Drawing Available)
Weight:
0.2kg
Table 8 - P300V34AI /B Specifications
7.6 WG4A-BR /B – Whirligig® Speed Sensor Mounting
Whirligig Specifications
Shaft Material:
Stainless Steel
Body Material:
Polypropylene
Bearing Type:
Sealed Stainless Steel
Mounting Thread Size:
M12
Maximum Speed:
1500 RPM
Number of Targets:
4
Protection:
IP40
Dimensions:
AutoCAD drawing available
Weight:
0.25kg
Table 9 - WG4A-BR /B Specifications
7.7 ADB910V3AI /B - Adjustable Depth Bearing Temperature Sensor
ADB910 Specifications
Thermistor Type:
NTC
Response Curve:
Exponential
(Please contact 4B for more details)
Cable Length:
3metres (9 feet)
Conductors:
2 Core; 22AWG; Polarity Independent
Probe length:
100mm
Body Mounting Thread:
1/8” Rc (BSPT)
Dimensions:
AutoCAD drawing available
Protection:
IP65
Weight:
0.25kg
Table 10 - ADB910V3AI /B Specifications
