4s3™ Semi-Automatic Sheet Heat Sealer
4s3™ Semi-Automatic Sheet Heat Sealer, Operation Manual V1.0
1.2 Instrument Overview
1.2.1 Sealer Parts
Casing and Control Panel Rear Power Interface
Heating Platen Plate Carrier
1.2.2 Control Panel
Operate, Open Drawer &
Incremental (up) Key
Three digit LED displaySet-up/Run Mode Key
Amber LED Status
Indicator
Close Drawer &
Decremental (down) Key
1.2.3 Rear Power Interface
Power Setting 115/230 Vac
and Fuse Holder
I/O Power Switch
Mains Power Plug
