Instruction manual BFC 21
Dimensions (all dimensions in mm, unless otherwise stated)
Size Description Unit BFC 28 BFC 30 BFC 50 BFC 60 BFC 80 BFC 100 BFC 120
A Overall height mm 1390 1910 1910 1910 2060 2060 2060
C Position on pallet mm - - - - 530 530 530
D Appliance diameter mm 705 705 705 705 850 850 850
E Depth mm - - - - 1000 1000 1000
F Width mm - - - - 900 900 900
G Diameter of flue gas discharge mm 100/150 100/150 100/150 100/150 130/200 130/200 130/200
H Height of flue gas outlet/air supply mm 1365 1905 1905 1905 1995 1995 1995
Hx x position flue gas outlet mm 265 265 265 265 310 310 310
Hy x position flue gas outlet mm 375 375 375 375 440 440 440
K Height of gas connection mm 1285 1815 1815 1815 1855 1855 1855
M Height of cold water supply mm 170 160 160 160 225 225 225
N Height of hot water outlet mm 1390 1910 1910 1910 2060 2060 2060
Ny y position of hot water outlet mm 205 205 205 205 205 205 205
P Height of cleaning opening mm 170 175 175 175 290 290 290
R Height of drain valve connection mm 85 75 75 75 225 225 225
S Height of T&P valve connection mm 900 1410 1410 1410 1425 1425 1425
W Height of condensation drain mm 150 150 150 150 240 240 240
1 Cold water supply connection (external) - R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
2 Hot water outlet (male) - R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
3 Gas control valve connection (external) - R
3
/
4
"R
3
/
4
"R
3
/
4
"R
3
/
4
"R
3
/
4
"R
3
/
4
"R
3
/
4
"
4 Drain valve connection (internal) - 1" 1" 1" 1"
3
/
4
"
3
/
4
"
3
/
4
"
5 T&P valve connection (female) - 1" - 11.5 NPT 1" - 11.5 NPT 1" - 11.5 NPT 1" - 11.5 NPT 1" - 11.5 NPT 1" - 11.5 NPT 1" - 11.5 NPT
6 Cleaning/inspection opening mm 95 x 70 95 x 70 95 x 70 95 x 70 95 x 70 95 x 70 95 x 70
7 Condensation drainage connection (female) - Ø 40 Ø 40 Ø 40 Ø 40 Ø 40 Ø 40 Ø 40
