T-H2-DV/T-H2-OS Service Manual
Ver. 1.01
95
CONFIDENTIAL
Item # Part # Description Common parts for other models
122 EKK1B Igniter plate
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS, T-K4-IN/OS,
T-D2-IN/OS, T-M50, T-M32
123 EKN74 Igniter
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS, T-K4-IN/OS,
T-D2-IN/OS, T-M50, T-M32
124 EKH5T Fan motor for exhaust
125 EX12X
Heat exchanger protection plate
(Front)
126 EX12Y
Heat exchanger protection plate
(Right)
127 EX12Z
Heat exchanger protection plate
(Left)
128 EK042 O-ring P20 NBR
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS, T-K4-IN/OS,
T-D2-IN/OS, T-M50
150 EW012 Screw M4×8 *
151 EW00D Pan screw M4×8 *
152 EW003 Screw M4×10 *
153 EW00H Pan screw M4×12 (W/Washer) *
154 EW006 Pan screw M4×10 *
155 EW005 Hex head screw M4×8 *
156 EKH4V Flange gasket for fan motor
157 EKK3G Silicon ring T-K3-OS, T-M50
401 EKH5P Heat exchanger assembly (DV)
402 EKN50 Silicon ring
T-K3, T-K3-Pro , T-K3-SP, T-KJr2-IN/OS, T-K4-IN/OS,
T-D2-IN/OS, T-M32
403 EKK26 Fuse fixing plate 18
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS, T-K4-IN/OS,
T-D2-IN/OS, T-M50, T-M32
404 EX02A Overheat-cut-off fuse
405 EX002 Heater 101 T-M50, T-M32
406 EKH40 Drain port
