A.O. Smith T-H2-DV User Manual

T-H2-DV/T-H2-OS Service Manual
Ver. 1.01
96
CONFIDENTIAL
Item # Part # Description Common parts for other models
407 EM222 Filter plug T-M50, T-M32
408 EZF25 O-ring P25 FKM
409 EX006 Water inlet filter T-M50, T-M32
410 EZH21 O-ring JASO# 1021 FKM
411 EM404 Water inlet T-M32
412 EZH16 O-ring JASO# 1016 FKM
413 EX021 Heater plate T-M50, T-M32
414 EX01H Fastener “16AG” T-M50, T-M32
415 EKK2P Outlet heater
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS, T-K4-IN/OS,
T-D2-IN/OS, T-M32
416 EK239 Outlet drain plug T-M32
417 EZF06 O-ring P6 FKM
418 EX00H Mixing thermistor T-M32
419 EZF04 O-ring P4 FKM
420 EZF16 O-ring P16 FKM
421 EKH74 Cold pipe
422 EKK38 Inlet thermistor T-K3, T-K3-Pro, T-D2-IN/OS, T-M50, T-M32
423 EKH32 Water control valve T-M50, T-M32
424 EW00A Screw M3×6
425 EKK27 Pipe heater fixing plate
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS, T-K4-IN/OS,
T-D2-IN/OS, T-M50, T-M32
426 EKJ47 Pipe heater 120
427 EW00L Pan screw M4×6 (W/Washer)
428 EZF15 O-ring P15 FKM
429 EKH33 Flow sensor T-M50, T-M32
430 EKH75 Hot pipe
431 EX137 Joint elbow
432 EKN34 Hi-limit switch T-K3, T-K3-Pro, T-K3-SP/OS, T-D2-IN/OS, T-M50, T-M32
433 EKK2T Output thermistor T-K3, T-K3-Pro, T-D2-IN/OS, T-M50, T-M32
434 EKH30 Fastener “4-11” T-K3, T-K3-Pro, T-D2-IN/OS, , T-M50, T-M32
