SubCompact Board GENE-6350
Chapter 2 Quick Installation Guide 2-9
CN18 TTL_LCD Connector
CN19 PS/2 Keyboard/ Mouse Connector
CN20 CRT Display Connector
CN21 (COM1) RS-232 Serial Port Connector
CN22 Front Panel
CN23 CompactFlash Disk Connector
FAN2 System Fan Connector
MPCI1 MINI PCI Connector
SODIMM1 DDR SODIMM Connector
