Aaeon GENE-6350 - DVI Connector (CN11); TV-Out Connector (CN12); RS-232;422;485 Serial Port Connector (CN14)

SubCompact Board GENE-6350
Chapter 2 Quick Installation Guide 2-17
2.22 DVI Connector (CN11)
Pin Signal Pin Signal
1 DVI TX1+ 2 DVI TX1-
3 GND 4 GND
5 DVI_TXCLK+ 6 DVI_TXCLK-
7 GND 8 +5V
9 HPDET 10 +5V
11 DVI_TX2+ 12 DVI_TX2-
13 GND 14 GND
15 DVI_TX0+ 16 DVI_TX0-
17 N.C. 18 N.C.
19 SM_DAT 20 SM_CLK
2.23 TV-out Connector (CN12)
Pin Signal Pin Signal
1 Y 2 CVBS
3 GND 4 GND
5 C 6 N.C.
7 GND 8 N.C.
2.24 RS-232/422/485 Serial Port Connector (CN14)
Pin Signal Pin Signal
1 DCD (422TXD-/485DATA-) 2 RXD (422RXD+)
3 TXD (422TXD+/485DATA+) 4 DTR (422RXD-)
5 GND 6 DSR
