SubCompact Board GENE-6350
Chapter 2 Quick Installation Guide 2-14
2.17 Floppy Connector (CN6)
Pin Signal Pin Signal
1 GND 2 #REDWC
3 GND 4 N.C.
5 GND 6 #DS1
7 GND 8 #INDEX
9 GND 10 #MOTOR A
11 GND 12 #DRIVE SELECT B
13 GND 14 #DRIVE SELECT A
15 GND 16 #MOTOR B
17 GND 18 #DIR
19 GND 20 #STEP
21 GND 22 #WRITE DATA
23 GND 24 #WRITE GATE
25 GND 26 #TRACK0
27 GND 28 #WRITE PROTECT
29 GND 30 #READ DATA
31 GND 32 #SIDE1
33 GND 34 #DISK CHANGE
2.18 Primary IDE Hard Drive Connector (CN7)
Pin Signal Pin Signal
1 IDE RESET 2 GND
3 DATA7 4 DATA8
5 DATA6 6 DATA9
7 DATA5 8 DATA10
9 DATA4 10 DATA11
