SubCompact Board GENE-6350
Chapter 2 Quick Installation Guide 2-21
2.31 Front Panel Connector (CN22)
Pin Signal Pin Signal
1 Power On Button
(
-
)
2 Power On Button
(
+
)
3 IDE LED (-) 4 IDE LED (+)
5 External Buzzer (-) 6 External Buzzer (+)
7 Power LED (-) 8 Power LED (+)
9 Reset Switch (-) 10 Reset Switch (+)
2.32 CompactFlash Disk Connector (CN23)
Pin Signal Pin Signal
1 GND 26 GND
2 DATA3 27 DATA11
3 DATA4 28 DATA12
4 DATA5 29 DATA13
5 DATA6 30 DATA14
6 DATA7 31 DATA15
7 CS#1 32 CS#3
8 GND 33 GND
9
GND
34 IO READ
10
GND
35 IO WRITE
11
GND
36 +5V
12
GND
37 IRQ15
13 +5V 38 +5V
14
GND
39 CSEL
15
GND
40 N.C.
16
GND
41 IDE RESET
17
GND
42 IO READY
18 ADDR2 43 N.C.
