Aaeon GENE-6350 - Digital IO Connector (CN8)

SubCompact Board GENE-6350
Chapter 2 Quick Installation Guide 2-15
11 DATA3 12 DATA12
13 DATA2 14 DATA13
15 DATA1 16 DATA14
17 DATA0 18 DATA15
19 GND 20 N.C.
21 REQ 22 GND
23 IO WRITE 24 GND
25 IO READ 26 GND
27 IO READ 28 GND
29 DACK 30 GND
31 IRQ 14 32 N.C.
33 ADDR1 34 UDMA DETECT
35 ADDR0 36 ADDR2
37 CS#1 38 CS#3
39 LED 40 GND
41 +5V 42 +5V
43 GND 44 N.C.
2.19 Digital IO Connector (CN8)
Pin Signal Pin Signal
1 IN1 2 IN2
3 IN3 4 IN4
5 OUT1 6 OUT2
7 OUT3 8 OUT4
9 +5V 10 GND
