SubCompact Board GENE-6350
Chapter 2 Quick Installation Guide 2-12
2.11 TFT_LCD Clock Selection (JP6)
JP6 Function
1-2 CLK (Default)
2-3 Reverse CLK
2.12 SIR Connector (CN1)
Pin Signal
1 +5V
2 N.C.
3 IRRX
4 GND
5 IRTX
6 N.C.
2.13 USB Connector (CN2)
Pin Signal Pin Signal
1 +5V 2 GND
3 USBD2- 4 GND
5 USBD2+ 6 USBD3+
7 GND 8 USBD3-
9 GND 10 +5V
2.14 USB Connector (CN3)
Pin Signal Pin Signal
1 +5V 2 GND
3 USBD0- 4 GND
