SubCompact Board GENE-6350
Chapter 2 Quick Installation Guide 2-8
2.5 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application. The table below shows the function of
each board's connectors:
Connectors
Label Function
CN1 SIR Connector
CN2 (USB3, USB4) USB Connector
CN3 (USB1, USB2) USB Connector
CN4 Audio Input/Output Connector
CN5 Audio 5.1 Channel Connector
CN6 Floppy Drive Connector
CN7 Primary IDE Hard Drive Connector
CN8 Digital IO Connector
CN9 LPT Port Connector
CN10 (COM3) RS-232 Serial Port Connector
CN11 DVI Connector
CN12 TV out Connector
CN13 (COM4) RS-232 Serial Port Connector
CN14 (COM2) RS-232/422/485 Serial Port Connector
CN15 (LAN) Ethernet 10/100 Base-T RJ-45 Phone Jack
CN16 Option ATX Power Connector
CN17 Big 4 Pin Power Connector
To Next Page
