SubCompact Board GENE-6350
Chapter 2 Quick Installation Guide 2-22
19 ADDR1 44 +5V
20 ADDR0 45 DASP
21 DATA0 46 DIAG
22 DATA1 47 DATA8
23 DATA2 48 DATA9
24 N.C. 49 DATA10
25 GND 50 GND
2.33 Fan Connector (Fan2)
Pin Signal
1 Speed Sense
2 +5V
3 GND
