SubCompact Board GENE-6350
Chapter 2 Quick Installation Guide 2-13
5 USBD0+ 6 USBD1+
7 GND 8 USBD1-
9 GND 10 +5V
2.15 Audio Input/Output Connector (CN4)
Pin Signal Pin Signal
1 MIC in 2 MIC Vcc
3 Audio Ground 4 CD_GND
5 LINE_in L 6 CD_L
7 LINE_in R 8 CD_GND
9 Audio Ground 10 CD_R
11 LINE_out L 12 LINE_out R
13 Audio Ground 14 Audio Ground
2.16 Audio 5.1 Channel Connector (CN5)
Pin Signal Pin Signal
1 Front out R 2 Audio Ground
3 Front out L 4 Audio Ground
5 Surround out R 6 Audio Ground
7 Surround out L 8 Audio Ground
9 Low Frequency Effect out 10 Audio Ground
11 Center out 12 Audio Ground
13 S/PDIF out 14 S/PDIF in
To Next Page
