VCCX2 Controller Technical Guide
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
Current
Duct Static
Setpoint
AI: 150 Current status of the
duct static setpoint
RSMZ 1
Condenser
Fan
AI: 151 Current RSMZ 1
condenser fan signal
RSMZ 1
VFD
Comp
Perc
AI: 152 Current RSMZ 1
VFD Compressor
Percentage
RSMZ 1
Discharge
Pressure
AI: 153 Current RSMZ 1
discharge
pressure
RSMZ 1
Suction
Pressure
AI: 154 Current RSMZ 1
Suction Pressure
RSMZ 1
Suction Line
Temp
AI: 155 Current RSMZ 1
Suction Line
Temperature
RSMZ 1
Saturation
Temp
AI: 156 Current RSMZ 1
Saturation
Temperature
RSMZ 1
Superheat
AI: 157 Current RSMZ 1
Superheat
Temperature
RSMZ 1
EEV
Position
AI: 158 Current RSMZ 1
EEV Valve Position
RSMZ 1
Warnings
AI: 159 Current RSMZ 1
Warnings
See RSMZ
Warnings Bits on
pages 134-135.
RSMZ 1
Comp VFD
Alarms 1
AI: 160 Current RSMZ 1
Comp VFD
Alarms 1
See RSMZ
Alarms 1 Bits on
pages 134-135.
RSMZ 1
Comp VFD
Alarms 2
AI: 161 Current RSMZ 1
Comp VFD
Alarms 2
See RSMZ
Alarms 2 Bits on
pages 134-135.
RSMZ 1
Comp VFD
Drive
Status
AI: 162 Current RSMZ 1
Comp VFD
drive status
See RSMZ
Drive Status
Bits on pages
134-135.
RSMZ 1
Compressor
Current
AI: 163 Current reading in Amps that
the RSMZ 1
compressor is using
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
RSMZ 1
Discharge
Line Temp
AI: 164 Current RSMZ 1
discharge line
temperature
RSMZ 1
Faults
AI: 165 Current RSMZ 1
Faults
See RSMZ
Faults Bits on
page 121.
RSMZ 1
Lockouts
AI: 166 Current RSMZ 1
Lockouts
See RSMZ
Lockouts Bits on
page 121.
RSMZ 2
Condenser
Fan
AI: 167 Current RSMZ 2
condenser fan signal
RSMZ 2
VFD
Comp
Perc
AI: 168 Current RSMZ 2
VFD Compressor
Percentage
RSMZ 2
Discharge
Pressure
AI: 169 Current RSMZ 2
discharge
pressure
RSMZ 2
Suction
Pressure
AI: 170 Current RSMZ 2
Suction Pressure
RSMZ 2
Suction Line
Temp
AI: 171 Current RSMZ 2
Suction Line
Temperature
RSMZ 2
Saturation
Temp
AI: 172 Current RSMZ 2
Saturation
Temperature
RSMZ 2
Superheat
AI: 173 Current RSMZ 2
Superheat
temperature
RSMZ 2
EEV
Position
AI: 174 Current RSMZ 2
EEV valve
position
RSMZ 2
Warnings
AI: 175 Current RSMZ 2
Warnings
See RSMZ
Warnings Bits on
pages 134-135.
RSMZ 2
Comp VFD
Alarms 1
AI: 176 Current RSMZ 2
Comp VFD
Alarms 1
See RSMZ
Alarms 1 Bits on
pages 134-135.
RSMZ 2
Comp VFD
Alarms 2
AI: 177 Current RSMZ 2
Comp VFD
Alarms 2
See RSMZ
Alarms 2 Bits on
pages 134-135.
APPENDIX C
-
VCCX2 BACnet
®
VCCX2 BACnet
®
Parameters
