VCCX2 Controller Technical Guide
VCCX2 TREND LOG BIT STRINGS
Item Bit Value Description
ExpRly
0 1 12 Relay Exp Relay #1
Congurable
1 2 12 Relay Exp Relay #2
Congurable
2 4 12 Relay Exp Relay #3
Congurable
3 8 12 Relay Exp Relay #4
Congurable
4 16 12 Relay Exp Relay #5
Congurable
5 32 12 Relay Exp Relay #6
Congurable
6 64 12 Relay Exp Relay #7
Congurable
7 128 12 Relay Exp Relay #8
Congurable
8 256 12 Relay Exp Relay #9
Congurable
9 512 12 Relay Exp Relay #10
Congurable
10 1024 12 Relay Exp Relay #11
Congurable
11 2048 12 Relay Exp Relay #12
Congurable
1A1Stat
1A2Stat
2A1Stat
2A2Stat
3A1Stat
3A2Stat
4A1Stat
4A2Stat
0 1 System On
1 2 Active Alarm
2 4 Disabled
3 8 Forced On
4 16 Forced O󰀨
5 32 Outdoor Air Lockout
6 64 System Not Used
7 128 Min Run Pending
8 256 Min O󰀨 Pending
9 512 Defrost Mode
Table 14: VCCX2 Trend Log Bit Strings (continued)
SEQUENCE OF OPERATIONS
Trend Log Bit String Decoding
