VCC-X CONFIGURATION
VCC-X Operator Interface SD
32
Confi guration Screen #40 - Exhaust Fan
Output
VCC-X Cnfg ID #
Exh Fan Volts
Min Volts: 0.0VDC
Max Volts: 10.0VDC
This confi guration option is available if Modulating Building Pres-
sure Control was confi gured on a previous screen. The following
will set the output voltage range for both Direct and Reverse Acting
Building Pressure Control. Defaults are 0 VDC Min Volts and 10
VDC Max Volts. Available options are:
Min Volts—Voltage at which the signal to exhaust fan,
exhaust damper, or OA damper will be at 0% for either
Direct or Reverse Acting Building Pressure control.
Max Volts—Voltage at which the signal to exhaust fan,
exhaust damper, or OA damper will be at 100% for
either Direct or Reverse Acting Building Pressure
control.
Description Minimum Default Maximum
Minimum Position Volts 0.0 0.0 10.0
Maximum Position Volts 0.0 10.0 10.0
Confi guration Screen #41 - Heat Pump Confi g
VCCX Cnfg ID 101
Heat Pump Config
No Heat Pump
Use < Or > To Change
Default is No Heat Pump. Available options are:
No Heat Pump—Unit is not a Heat Pump.
Air/Air Fail to Heat—Heat Pump unit activates its
Reversing Valve during Cooling operation.
Air/Air Fail to Cool—Heat Pump unit activates its
Reversing Valve during Heating operation.
WSHP Fail to Heat—Water Source Heat Pump unit
activates its Reversing Valve during Cooling operation.
WSHP Fail to Cool—Water Source Heat Pump unit
activates its Reversing Valve during Heating operation.
VCC-X Confi guration Screens
Confi guration Screen #42 - WSHP Glycol %
VCCX Cnfg ID 101
WSHP Glycol
Percentage: 0%
Use < Or > To Change
If this is a Water Source Heat Pump Unit, this screen allows you to
confi gure the percentage of glycol in your unit. Options are 0% to
40% in 5% increments. Default is 0%.
Confi guration Screen #43 - Aux Heat Type Value
VCCX Cnfg ID 101
Aux Heat Type
No Aux Heat
Use < Or > To Change
If this is a Heat Pump, choose the appropriate Aux Heat option.
Default is No Aux Heat. Available options are:
No Aux Heat—This unit does not have Heat Pump
Auxiliary Heat.
Staged Only—This unit has a stage(s) of Auxiliary
Heat. Multiple relays can be confi gured as Aux Heat in
which case the relays will stage up as required.
Modulating Only—This unit has a form of modulating
heat being used as Auxiliary Heat. ModGas cannot be
used as the modulating heat source.
Modgas-x then Staged—This unit has modulating gas
heat that will be used as the 1st form of Aux Heat
followed by a stage(s) of Aux Heat if applicable.
Mod Heat then Staged—Fully modulating Heat as the
1
st
form of Aux Heat and Stage(s) of Heat as the 2
nd
form of
Heat.
Confi g Screen #44 - Dehumidifi cation Control
VCC-X Cnfg ID #
Dehum. Control:
None
USE < or > TO CHANGE
If using Dehumidifi cation choose the appropriate Dehumidifi cation
option. Default is None. Available options are:
None—The unit does not have a Dehumidifi cation Mode.
Only Occupied Vent—The unit can only enter
Dehumidifi cation during the Occupied Vent Mode (when
there is no call for Cooling or Heating).
Only Vent Anytime—The unit can only enter
Dehumidifi cation during the Vent Mode (when there
is no call for Cooling or Heating) in both the Occupied
and Unoccupied operation.
