VCC-X CONFIGURATION
VCC-X Operator Interface SD
34
Confi guration Screen #51 - Monitor Supply Air
Airfl ow
VCC-X Cnfg ID #
Monitor SA Airflow
NO
USE < or > TO CHANGE
Select YES if you have an Airfl ow Monitoring station measuring the
CFM of the Supply Air airfl ow stream of this unit. Default is NO.
Confi guration Screen #52 - Supply Airfl ow
Duct Size
VCC-X Cnfg ID #
Supply Airflow Duct
Size: 0.00
[ In Square Feet ]
For the controller to properly calculate the Supply Air CFM, you need
to enter the area in square feet of the Supply Air duct/damper. When
measuring the Supply Air duct damper area, be sure to measure the
inside dimensions of the damper. The duct size needs to be accurate
to two decimal places. The more accurate the measurements, the
more accurate the CFM reading will be. Default is 0.
Description Minimum Default Maximum
Supply Air Airfl ow Duct Size 0 0 200.00
Confi guration Screen #53 - Monitor Return Air
Airfl ow
VCC-X Cnfg ID #
Monitor RA Airflow
NO
USE < or > TO CHANGE
Select YES if you have an Airfl ow Monitoring station measuring the
CFM of the Return Air airfl ow stream of this unit. Default is NO.
Confi guration Screen #54 - Return Airfl ow
Duct Size
VCC-X Cnfg ID #
Return Airflow Duct
Size: 0.00
[ In Square Feet ]
For the controller to properly calculate the Return Air CFM, you need
to enter the area in square feet of the Return Air duct/damper. When
VCC-X Confi guration Screens
measuring the Return Air duct damper area, be sure to measure the
inside dimensions of the damper. The duct size needs to be accurate
to two decimal places. The more accurate the measurements, the
more accurate the CFM reading will be. Default is 0.
Description Minimum Default Maximum
Return Air Airfl ow Duct
Size
0 0 200.00
Confi guration Screen #55 - Monitor Exhaust
Airfl ow
VCC-X Cnfg ID #
Monitor Exh Airflow
NO
USE < or > TO CHANGE
Select YES if you have an Airfl ow Monitoring station measuring the
CFM of the Exhaust Air airfl ow stream of this unit. Default is NO.
Confi guration Screen #56 - Exhaust Airfl ow
Duct Size
VCC-X Cnfg ID #
Exhaust Airflow Duct
Size: 0.00
[ In Square Feet ]
For the controller to properly calculate the Exhaust Air CFM, you
need to enter the inside area in square feet of the Exhaust Air duct/
damper. When measuring the Exhaust Air damper area, be sure to
measure the inside dimensions of the damper. The duct size needs to
be accurate to two decimal places. The more accurate the measure-
ments, the more accurate the CFM reading will be. Default is 0.
Description Minimum Default Maximum
Exhaust Airfl ow Duct Size 0 0 200.00
Confi guration Screen #57 - Morning Warm Up
VCC-X Cnfg ID #
Morning Warm Up
None
USE < or > TO CHANGE
You can choose between the following Morning Warm Up options.
Default is None. Available options are:
 None— There is no Morning Warm Up required.
 Stand Alone—The VCC-X Controller is not
communicating to Orion VAV Box controls, but a
Morning Warm Up Relay can be confi gured to signal
boxes by others to open.
