Status Screen #27 - Return Air Damper Signal
& Return Air Bypass Damper Signal
VCC-X v2.00 ID 101
Return Dmper: XXX%
Bypass Dmper: XXX%
[Optional Outputs]
Line 2 Current Return Air Damper Signal
If confi gured for Return Air Bypass Control, this
indicates the current Output Signal percentage being
sent to the Return Air Damper Actuator. If you haven’t
confi gured a Return Air Bypass Damper, [No Return
Dmp Confg] will be displayed instead.
Line 3 Current Return Air Bypass Damper Signal
If confi gured for Return Air Bypass Control, this
indicates the current Output Signal percentage being
sent to the Return Air Bypass Damper Actuator. If you
haven’t confi gured a Return Air Bypass Damper, [No
Bypass Dmp Confg] will be displayed instead.
Line 4 Indicates That These Are Optional Outputs
This output may or may not have live data to display.
Status Screen #28 - Reset Voltage Signal
VCC-X v2.00 ID 101
Reset Voltage Signal
0.0VDC
Line 2-3 Reset Voltage Signal
If using a Remote Voltage Signal to reset the Supply Air
Temperature setpoint, this screen will display the current
Reset Voltage Signal being sent to the Controller.
VCC-X Status Screens
Status Screens #29-#36 - VCC-X Relays
VCC-X v1.02 ID #
On Board Rly 1-8
FAN
ON/OFF
Line 2 On Board Relays 1-8 Status
Line 3 Current description of what this Relay is
confi gured for
On screen 29, this line will display FAN.
On screens 30-36, this line will indicate the relay’s use.
Possible options are:
• Not Used (Default) • Cool Stage
• Heat Stage • HP Aux Heat
• HP Emer Heat • Mod Heat Enable
• Mod Cool Enable • Warmup / Cooldown
• ReHeat • PreHeat
• Low Ambient • Exhaust Fan
• Economizer • Heat Wheel
• Occupied Mode • Override Mode
• Alarm Active
Line 4 Current Relay Status
This line will display the ON/OFF condition for that
relay. FORCED ON or FORCED OFF will appear if
this Relay is in a Force Mode. Possible options are as
follows:
ON OFF
FORCED ON FORCED OFF
To Next Page
