AAON SS1063 User Manual

VCC-X Operator Interface SD
VCC-X STATUS
63
Status Screens #37-#41 - EM1 Relays
VCC-X v1.02 ID #
Main Exp Rly 1-5
Relay Name
ON/OFF
Line 2 On Board Relays 1-5 Status
Line 3 Current description of what this Relay is
confi gured for
On screens 37-41, this line will indicate the relay’s use.
Possible options are:
• Not Used (Default) • Cool Stage
• Heat Stage • HP Aux Heat
• HP Emer Heat • Mod Heat Enable
• Mod Cool Enable • Warmup / Cooldown
• ReHeat • PreHeat
• Low Ambient • Exhaust Fan
• Economizer • Heat Wheel
• Occupied Mode • Override Mode
• Alarm Active
Line 4 Current Relay Status
This line will display the ON/OFF condition for that
relay. FORCED ON or FORCED OFF will appear if
this Relay is in a Force Mode. Possible options are as
follows:
ON OFF
FORCED ON FORCED OFF
Status Screens #42-#53 - 12 Relay Expansion
Module Relays
VCC-X v1.02 ID #
12 Rly Bd Rly 1-12
Relay Name
ON/OFF
Line 2 On Board Relays 1-12 Status
Line 3 Current description of what this Relay is
confi gured for
On screens 42-53, this line will indicate the relay’s use.
Possible options are:
• Not Used (Default) • Cool Stage
• Heat Stage • HP Aux Heat
• HP Emer Heat • Mod Heat Enable
• Mod Cool Enable • Warmup / Cooldown
• ReHeat • PreHeat
• Low Ambient • Exhaust Fan
• Economizer • Heat Wheel
• Occupied Mode • Override Mode
• Alarm Active
Line 4 Current Relay Status
This line will display the ON/OFF condition for that
relay. FORCED ON or FORCED OFF will appear if this
Relay is in a Force Mode. Possible options are as
follows:
ON OFF
FORCED ON FORCED OFF
