VCC-X STATUS
VCC-X Operator Interface SD
64
VCC-X Status Screens
Status Screens #54-## - Alarm Status
VCC-X v1.02 ID #
NO ALARMS PRESENT
VCC-X v2.00 ID 101
ALARMS PRESENT
Push Alarms
Button to View
Line 2 NO ALARMS OR ALARMS PRESENT
Lines
3-4 Push Alarms Button to View
Press <ALARMS>. The Unit Selection Screen will be displayed.
Enter Unit Address
Then Press Enter
Selected Unit #_1
Press Down
Enter the Unit ID of the controller you wish to search. You must type
in the number, even if it is “1” and
press <ENTER>. Then press <>.
The System Manager or Service Tool will search for any active
alarms on the unit and one of the following screens will appear:
Bad SAT Sensor
Bad RAT Sensor
Bad OAT Sensor
Bad Space Sensor
Bad CO
2
Sensor
Bad Building Pressure Sensor
Missing Outdoor Air CFM Sensor
Missing Exhaust Air CFM Sensor
Missing Supply Air CFM Sensor
Missing Return Air CFM Sensor
Mechanical Cooling Failure
Mechanical Heating Failure
Fan Proving Alarm
Dirty Filter Alarm
Emergency Shutdown
Relay Runtime
No Economizer Feedback
Title 24 Economizer Air Temperature Sensor Failure
Title 24 Economizer Damper Failure
Title 24 Economizer Excess Outdoor Air
Title 24 Economizer Not Economizing When It Should
Title 24 Economizer Economizing, But It Shouldn’t
High Supply Air Temperature Cutoff
Low Supply Air Temperature Cutoff
High Control Temperature
Low Control Temperature
Missing RSM #1
Missing RSM #2
Missing RSM #3
Missing RSM #4
Missing PREHEAT-X
Missing MHGRV-X
Missing MODGAS-X
Missing EM1
Missing 12RLY
P
ress <> to scroll through all active alarms.
For Alarm Defi nitions, see the VCC-X Controller
Technical Guide.
