56VCCX-IP Controller Technical Guide
SEQUENCE OF OPERATIONS
Trend Logs
VCCX-IP TREND LOG BIT STRINGS
Item Bit Value Description
ExpRly
0 1 12 Relay Exp Relay #1 Congurable
1 2 12 Relay Exp Relay #2 Congurable
2 4 12 Relay Exp Relay #3 Congurable
3 8 12 Relay Exp Relay #4 Congurable
4 16 12 Relay Exp Relay #5 Congurable
5 32 12 Relay Exp Relay #6 Congurable
6 64 12 Relay Exp Relay #7 Congurable
7 128 12 Relay Exp Relay #8 Congurable
8 256 12 Relay Exp Relay #9 Congurable
9 512 12 Relay Exp Relay #10 Congurable
10 1024 12 Relay Exp Relay #11 Congurable
11 2048 12 Relay Exp Relay #12 Congurable
RSMV/RSMD
1A1Stat
1A2Stat
2A1Stat
2A2Stat
3A1Stat
3A2Stat
4A1Stat
4A2Stat
0 1 System On
1 2 Active Alarm
2 4 Disabled
3 8 Forced On
4 16 Forced O󰀨
5 32 Outdoor Air Lockout
6 64 System Not Used
7 128 Min Run Pending
8 256 Min O󰀨 Pending
9 512 Defrost Mode
RSMV/RSMD
1Relay1
2Relay2
3Relay3
4Relay4
0 1 Relay 1 Active
1 2 Relay 2 Active
2 4 Relay 3 Active
3 8 Relay 4 Active
4 16 Relay 5 Active
5 32 Unloader 1 Active
6 64 Unloader 2 Active
Table 19: VCCX-IP Trend Log Bit Strings (continued)
