APPENDIX C: BACNET GUIDE
BACnet Protocol Implementation Conformance Statement - VCCX-IP
BACnet® Protocol Implementation Conformance Statement
Date: January 2023
Vendor: AAON
Product: VCCX-IP
Product Model Number: ASM07424
Product Version: FW 1.09
Product Description: HVAC Unit Controller
BACnet Protocol Revision: Revision 15 (ANSI/ASHRAE Standard 135-2019)
BACnet® Protocol Implementation Conformance Statement
K.1.2 BIBB – Data Sharing-ReadProperty-B (DS-RP-B)
K.1.4 BIBB – Data Sharing-ReadPropertyMultiple-B (DS-RPM-B)
K.1.8 BIBB – Data Sharing-WriteProperty-B (DS-WP-B)
K.5.2 BIBB – Device Management-DynamicDeviceBinding-B (DM-DDB-B)
K.5.4 BIBB – Device Management-DynamicObjectBinding-B (DM-DOB-B)
K.5.6 BIBB – Device Management-DeviceCommunicationControl-B (DM-DCC-B)
BACnet Standardized Device Profile
L.4 BACnet Application Specific Controller (B-ASC)
Standard Object Types Supported
Analog Input: Optional properties supported: Description
Analog Value: Optional properties supported: Description
Binary Input: Optional properties supported: Description, Inactive_Text, Active_Text
Binary Value: Optional properties supported: Description, Inactive_Text, Active_Text
Device Object: Optional properties supported: Description, Location, Serial_Number
Multi-state Input: Optional properties supported: Description, State_Text
Multi-state Value: Optional properties supported: Description, State_Text
For all supported objects, device does not support CreateObject or DeleteObject.
There are no proprietary objects.
Data Link Layer Options
MS/TP Master: Supported Baud rates: 9.6K, 19.2K, 38.4K, 57.6K, 76.8K
BACnet/IP, ‘DIX’ Ethernet
Segmentation Support
Neither segmented requests nor segmented responses are supported.
