70VCCX-IP Controller Technical Guide
APPENDIX B: LCD SCREENS
Screen Descriptions
Status Screens
Refer to the following map when navigating through the Status
Screens. From the Status Screen, press <ENTER> to scroll through
the screens.
STATUS SCREENS
Screen Text Description
Status Status screens.
OperMode Operation mode. Options are:
• UNOCCUPY (Unoccupied)
• OCCUPIED
• OVERRIDE
• HOL UNOC (Holiday unoccupied)
• FRC OCC (Force occupied)
• FRC UNOC (Force unoccupied)
• REM OCC (Remote occupied)
• ZONEHEAT (Zone heat)
• ZONECOOL (Zone cool)
• ZONE OVR (Zone override)
HvacMode HVAC mode. Options are:
• OFF
• VENT
• COOL
• HEAT
• VENT RH
• COOL RH
• HEAT RH
• WARMUP
• PURGE
• DEFROST
• COOLDOWN
Spc Temp
XX.X°
Space temperature.
Spc RH
X.X %
Space humidity. 0.00% - 100%.
SA Temp
XX.X°
Supply air temperature.
RA Temp
XX.X°
Return air temperature.
OA Temp
XX.X°
Outdoor air temperature.
OA RH
X.X %
Outdoor air humidity. 0.00% - 100%.
CO2Level
X ppm
Carbon dioxide level. 0.00 ppm to 5000 ppm.
Table 29: Status Screens
