ABB 500 - Page 57

Chapter 4 - Signals and Troubleshooting
DCS 500B / DCP 500B Operating Instructions
IV A 4 - 5
Code
seven
segm.
display
Text on
LCD of control panel
CDP 31x
Definition /
Action
Status
signal
(FAULT_WORD_1/2)
Remark
F 8
Current rise fault
Actual current changed faster than allowed
The rate of current change is monitored.
Check: - Setting of current reference slope
[P406] and CURRENT_RISE_MAX
[P418];
Level and setting of line voltage
and motor voltage; setting of
current controler
11103 bit 10 (2)
S21.232
and
higher
F 14
Speed meas. fault
Speed feedback (measurement) fault
Check: - Incremental encoder and connec-
tion cable, encoder power supply
(feedback might be too low);
- Tacho polarity and voltage
(does a total mismatch exist?)
- Electronic boards SDCS-CON-x,
SDCS-IOB-3, SDCS-POW 1;
- Connection converter – armature
circuit open?
- Correct setting for selection of
speed feedback monitoring?
11102 bit 5 (3)
F 17
Type coding fault
(Converter) Type coding fault
SDCS-PIN-xx board not connected to board
SDCS-CON-x or SDCS-PIN-xx not coded.
Check: - Flat cables X12 and X13 O.K.?
- Faulty coding on SDCS-PIN-xx?
- Correct coding of unit size
C4?
Note: This fault signal will be shown, if jumper S2 (on board
SDCS-CON-x) is in position 1–2 while switching ON the elec-
tronics supply. In that case select BACKUP-STOREMODE
[11202], save the paramter set, switch OFF the electronics,
reset jumper S2 and switch ON the electronics again.
11102 bit 8 (1)
Can
not be
reset
F 18
Backup read fault
Backup read fault (Parameter saving fault)
Cause: Wrong or missing checksum, data error
while writing or reading.
Note: Try again BACKUP-STORE-MODE; for that purpose
- Move jumper S2 (on board
SDCS-CON-x) to Pos. 1–2
with electronics supply switched OFF;
- Switch ON electronics again;
- Select BACKUPSTOREMODE [11202];
- Save default parameter set;
- Switch OFF electronics;
- Reset jumper S2 to ist original position;
- Switch ON electronics again.
If display shows F 18 once again, change SDCS-CON-x
board!
11102 bit 9 (1)
Can
not be
reset
