ABB A175-L35 - Table 48 Cartridge Group with Part

Operation Manual / 4 Product description / A100-L
12
Spare p
arts Page 109 /
113
© Copyright 2016 ABB. All rights reserved.
HZTL4034_EN
Revision H
November 2016
Cartridge group
Part number
Designation
21000 Turbine
25000 Compressor wheel
25008 Threaded stud
25009 Ring nut
25011 O-ring
32001 Thrust bearing
32101 Radial bearing, compressor end
32102 Radial bearing, turbine end
32105 Floating disc
32106 Axial bearing
32109 Sealing disc
32159 Locking screw
32174 O-ring
42001 Bearing casing
42008 Socket screw
42011 O-ring
42015 Sealing cover
42039 Hexagon-head screw
42041 Gasket
42059 Hexagon-head screw
42064 Hexagon-head screw
42185 Socket screw
42186 O-ring
42295 Pressure adjusting unit
42300 Partition wall
42305 O-ring
42306 O-ring
42307 O-ring
42320 Socket screw
42458 Blind flange
86505 Speed sensor
86506 (in the customer spare part set) O-ring
Table 48: Cartridge group with part numbers
