ABB AC 800M

Thin Cable Section 2 Transmission Media and Components
32 9ARD000015-600
Table 22 lists the topology details of Thin cable.
Bend Radius 20 x diameter (installation) / 7 x diameter
(fixed)
Operating ambient temperature -20° C .. +70° C @ 1.5 amps; de-rate electric
current linearly to zero @ 80° C
Storage temperature -40° C .. +85° C
Pull tension 65 lbs maximum
Connector Compatibility Mini, Micro, Open
Topology Compatibility Trunk, Drop
Table 22. Thin Cable Topology
Data Rate
Max
Cable
Distance
Trunk
Exchange
(Thick Cable)
Cumulative
Drop
Maximum Drop
125 kb 100 m (328 ft) 5.0 156 m (512 ft) 6 m (20 ft)
250 kb 100 m (328 ft) 2.5 78 m (256 ft) 6 m (20 ft)
500 kb 100 m (328 ft) 1.0 39 m (128 ft) 6 m (20 ft)
Table 21. Environmental Characteristics of General Specification for Thin Cables (Continued)
Applicable Environmental
Characteristics
Specification
