ABB AC 800M Installation Manual

Section 2 Transmission Media and Components Flat Cable II
9ARD000015-600 41
Electrical
Table 38
General Specification
Physical
Table 39
Electrical
Table 40
Environmental
Table 41
Table 35. Physical Characteristics of Data Pair Specification for Flat Cable II
Physical Characteristics Specification
Conductor pair 0.55 mm
2
maximum (20 AWG
maximum) Cu (Sn plating),
20 maximum strands of 0.18 mm,
1 twist/15 mm
Insulation diameter 2.54 mm +/- 0.06 mm
Colors White
Blue
Pair Twist/ft N/A
Tape shield over pair N/A
Table 36. Electrical Characteristics of Data Pair Specification for Flat Cable II
Electrical Characteristics Specification
Impedance 120 ohms +/- 10% (at 500 KHz)
Propagation delay 1.78 nSec/ft (maximum)
Table 34. Specifications and their corresponding
Table Numbers (Continued)of Flat Cable II
Characteristics Table Number
