E-Clipse Bypass Configurations for ACH550 Drives 89
Technical Data
Fuses, 500…600 Volt, Fuses
Line Reactor
The ACH550 E-Clipse Bypass may contain optional input line reactors to provide
additional input impedance on the VAC line. This impedance is in addition to the
approximately 5% equivalent input impedance provided by internal reactors that are
standard in the drive.
Drive’s Power Connection Terminals
The following tables list power and motor cable terminal sizes for connections to an
input circuit breaker or disconnect switch, a motor terminal block and ground lugs.
The tables also list torque that should be applied when tightening the terminals.
500…600 Volt
Frame
Size
Drive Input Fuse Ratings
HP Identification
Amps
(600V)
Bussmann
Type
2 ACH550-xxR-02A7-6 R2 30 KTK-R-30
3 ACH550-xxR-03A9-6 R2 30 KTK-R-30
5 ACH550-xxR-06A1-6 R2 30 KTK-R-30
7.5 ACH550-xxR-09A0-6 R2 30 KTK-R-30
10 ACH550-xxR-011A-6 R2 30 KTK-R-30
15 ACH550-xxR-017A-6 R2 30 KTK-R-30
20 ACH550-xxR-022A-6 R3 60 JJS-60
25 ACH550-xxR-027A-6 R3 60 JJS-60
30 ACH550-xxR-032A-6 R4 100 JJS-100
40 ACH550-xxR-041A-6 R4 100 JJS-100
50 ACH550-xxR-052A-6 R4 100 JJS-100
60 ACH550-xxR-062A-6 R4 100 JJS-100
75 ACH550-xxR-077A-6 R6 200
170M1370
or
170M2619
100 ACH550-xxR-099A-6 R6 200
125 ACH550-xxR-125A-6 R6 200
150 ACH550-xxR-144A-6 R6 200
To Next Page
