E-Bypass Configurations for ACH550 Drives 41
Technical Data
Vertical Enclosure Terminals, 500…600 Volt Units
Standard Enclosure Terminals, 208…240 Volt Units,
500…600 Volt
Frame
Size
Maximum Wire Size Capacities of Power Terminals
HP Identification
Circuit
Breaker
Disconnect
Switch
Motor
Terminal
Block
Ground
Lugs
2 ACH550-Vx-02A7-6 R2
#3
44 in-lb
#8
7 in-lb
#6
13 in-lb
#4
35 in-lb
3 ACH550-Vx-03A9-6 R2
5 ACH550-Vx-06A1-6 R2
7.5 ACH550-Vx-09A0-6 R2
10 ACH550-Vx-011A-6 R2
15 ACH550-Vx-017A-6 R2
20 ACH550-Vx-022A-6 R3
#4
18 in-lb
#2/0
120 in-lb
#2
50 in-lb
25 ACH550-Vx-027A-6 R3
30 ACH550-Vx-032A-6 R4
40 ACH550-Vx-041A-6 R4
50 ACH550-Vx-052A-6 R4
60 ACH550-Vx-062A-6 R4
#3
44 in-lb
208…240 Volt
Frame
Size
Maximum Wire Size Capacities of Power Terminals
HP Identification
Circuit
Breaker
Disconnect
Switch
Motor
Terminal
Block
Ground
Lugs
1 ACH550-Bx-04A6-2 R1
#6
13 in-lbs
#6
13 in-lbs
#6
13 in-lbs
#4
35 in-lbs
1.5 ACH550-Bx-06A6-2 R1
2 ACH550-Bx-07A5-2 R1
3 ACH550-Bx-012A-2 R1
5 ACH550-Bx-017A-2 R1
7.5 ACH550-Bx-024A-2 R2
10 ACH550-Bx-031A-2 R2/R3
#2/0
120 in-lbs
#2/0
120 in-lbs
#2/0
120 in-lbs
#2
50 in-lbs
15 ACH550-Bx-046A-2 R3
20 ACH550-Bx-059A-2 R3
25 ACH550-Bx-075A-2 R4
30 ACH550-Bx-088A-2 R4
300 MCM
275 in-lbs
#1/0
70 in-lbs
250 MCM
275 in-lbs
3 x #3/0
250 in-lbs
40 ACH550-Bx-114A-2 R4
50 ACH550-Bx-143A-2 R6
350 MCM
200 in-lbs
60 ACH550-Bx-178A-2 R6
400 MCM
375 in-lbs
75 ACH550-Bx-221A-2 R6
350 MCM
275 in-lbs
100 ACH550-Bx-248A-2 R6
