ABB ACH550 - E- Bypass Control Panel Connections

E-Bypass Configurations for ACH550 Drives 43
Technical Data
Standard Enclosure Terminals, 500…600 Volt Units
500…600 Volt
Frame
Size
Maximum Wire Size Capacities of Power Terminals
HP Identification
Circuit
Breaker
Disconnect
Switch
Motor
Terminal
Block
Ground
Lugs
2 ACH550-Bx-02A7-6 R2
#6
13 in-lb
#6
13 in-lb
#6
13 in-lb
#4
35 in-lb
3 ACH550-Bx-03A9-6 R2
5 ACH550-Bx-06A1-6 R2
7.5 ACH550-Bx-09A0-6 R2
10 ACH550-Bx-011A-6 R2
15 ACH550-Bx-017A-6 R2
20 ACH550-Bx-022A-6 R3
25 ACH550-Bx-027A-6 R3
#2/0
120 in-lb
#2/0
120 in-lb
#2/0
120 in-lb
#2
50 in-lb
30 ACH550-Bx-032A-6 R4
40 ACH550-Bx-041A-6 R4
50 ACH550-Bx-052A-6 R4
60 ACH550-Bx-062A-6 R4
75 ACH550-Bx-077A-6 R6
300 MCM
275 in-lb
#10
70 in-lb
#2/0
53 in-lb
3 x #3/0
250 in-lb
100 ACH550-Bx-099A-6 R6
125 ACH550-Bx-125A-6 R6
300 MCM
275 in-lb
250 MCM
275 in-lb
150 ACH550-Bx-144A-6 R6
