Technical data
Contents of this chapter
This chapter contains the technical specifications of the drive, for example, the ratings,
sizes and technical requirements, provisions for fulfilling the requirements for CE and
other markings.
Ratings
￭ IEC ratings
The nominal ratings for the drives with 50 Hz and 60 Hz supply are given below. The
symbols are described in section Definitions (page 199).
IEC RATINGS
Output ratingsInput
rating
Frame
size
ACQ580-
07…
Heavy-duty
use
Light-duty useNominal ratings
P
Hd
I
Hd
P
Ld
I
Ld
P
N
S
n
I
2
I
max
I
1
kWAkWAkWkVAAAA
U
n
= 400 V
551057513875100145178145R60145A-4
751459016190117169247169R70169A-4
90169110196110143206287206R70206A-4
110206132234132170246350246R80246A-4
132246*160278160203293418293R80293A-4
160293200345200251363498363R90363A-4
