ABB ACQ580-07 - Frames R10 and R11 (+B054: IP42, UL Type 1 Filtered)

Frames R10 and R11 (+B054: IP42, UL Type 1 Filtered)
644[25,35”]
min. 400
[15,75”]
143
[5,63”]
2001.5[78,8”]
2144.5[84,43”]
698[27,48”]
600[23,62”]
57
[2,24”]
800[31,5”]
830[32,67”]
15[0,6”]15[0,6”]
25[0,98”]
25[0,98”]
550[21,65”] 550[21,65”]
650[25,6”]
25
[0,98”]
75
[2.95”]
18
[0.7”]
75
[2.95”]
25
[0,98”]
182[7,16”]
112[4,4”]
201[7,91”]
82[3,22”]
95[3,74”]
257[10,11”]
82[3,22”]
95[3,74”]
Ø20[0,78”]
Ø30[1,18”]
391[15,4”]
231[9,09”]
Ø60[2,36”]
Dimension drawings 267
