Common mode filter (option +E208) behind
the mounting plate
20Lifting lugs8
du/dt filter (option +E205)21Cabinet door fan9
￭ Cabinet layout – R8 and R9 (bottom entry and exit of cables)
The cabinet layout of frame R9 with du/dt filter (option +E205) is shown below. Degree
of protection IP42 (UL Type 1 Filtered [option +B054]). Frame R8 looks similar.

6
21
17
18
8
7
4
4
3
1
5
2
A
B
C
5
11
10
13
15
16
12
20
9
19
14
Auxiliary voltage transformer T2110Cabinet door closedA
Input cable connection terminals11Cabinet door openB
Main switch-disconnector (Q1)12Cabinet door open, mounting plates and
cabinet shrouds removed
C
AC fuses13Drive control panel1
Main contactor (Q2, option +F250)14Operating switch2
Power cable connection terminals of the
drive module behind the shroud
15Main switch handle3
Drive module16Gratings for cooling air in4
40 Operation principle and hardware description
