Update notice
3AXD50000695317 Rev BCode
From 2021-03-01 until the next revision of the manual.Valid
Added descriptionsContents
This notice concerns these manuals:
LanguageRevisionManual codeManual name
ENEnglishE3AXD50000045816
ACH580-07 hardware manual
ENEnglishE3AXD50000045817
ACQ580-07 hardware manual
ENEnglishE3AXD50000045815
ACS580-07 hardware manual
ADDED: Connectivity for wired remote monitoring (option
+K496)
This option provides a gateway to connect the drive to ABB Ability™ via a local Ethernet
network. Includes NETA-21 remote monitoring tool and FMBT-21 Modbus/TCP adapter
module.
The NETA and FMBT-21 are installed at the factory and wired internally. An Ethernet
cable for customer connection is routed from the NETA to the external control connections
mounting plate (number 6 in the layout drawing for frames R6...R9, number 12 for frames
R10 and R11). Use an RJ45 coupler (not included) to connect your Ethernet cable to
the additional Ethernet cable.
Code
(English)
Manual
3AUA0000096939
NETA-21 remote monitoring tool user’s manual
3AUA0000096881
NETA-21 remote monitoring tool installation and start-up guide
3AXD50000158607
FMBT-21 Modbus/TCP adapter module user’s manual
3AXD50000158560
FMBT-21 Modbus/TCP adapter module quick installation and start-up guide
ADDED: Connectivity for wireless remote monitoring (option
+K497)
This option provides a gateway to connect the drive to ABB Ability™ via a wireless 4G
network. Includes NETA-21 remote monitoring tool, FMBT-21 Modbus/TCP adapter
module and modem.
Update notice 1
