26
Group 01
OPERATING DATA
0128 LAST FAULT
Last recorded fault (0 = no fault). See “Diagnostics” starting on page
81.
Can be cleared with the control panel by pressing UP and DOWN
buttons simultaneously when in parameter set mode.
Group 10
COMMAND INPUTS
1003 DIRECTION
Rotation direction lock.
1 =
FORWARD
2 = REVERSE
3 = REQUEST
If you select REQUEST, the direction is set according to the given
direction command.
Default: 3 (
REQUEST)
!
Group 11
REFERENCE SELECT
1105 EXT REF1 MAX
Maximum frequency reference in Hz.
Range: 0 -300 Hz
Default value: 50 Hz
Group 12
CONSTANT SPEEDS
1202 CONST SPEED 1
Range for all constant speeds: 0 - 300 Hz
Default value: 5 Hz
1203
CONST SPEED 2
Default value: 10 Hz
1204
CONST SPEED 3
Default value: 15 Hz
.
Code Name User S
